Screw extrusion dehydrator adopts the principle of superposition compression, widely used in the chemical industry. When the machine operating, it rotate slowly and no temperature rise.
Send Message
For some materials to be recycled, this screw press extruders can fully separate solids and liquids to maximize your recycling value.
For some materials that need to be handed over to a third party, your disposal costs can be reduced by processing with a this screw press dehydrator.
For some materials that need to be made into finished products, the back-end treatment energy consumption can be reduced through the treatment of the screw extrusion dehydrator.
If you have such problem needs to be solved, feel free to contact us.
Zhongtian Xinghuo machinery has professional technology to produce screw press dewatering machine!
1.Continuous operation, save human cost.
2.Low speed stable operation, material temperature does not rise.
3.Dewatering juice for organic materials.
4.Separate slag and liquid for inorganic materials.
5.Adopts the superposition compression principle, not blocking screen stencil.
|
Model |
Capacity（t/h） |
screw diameter（mm） |
rotate speed（r/min） |
Power（kw） |
· |
Weight（t） |
|
ZTZY-120 |
0.1～0.3/0.26 |
120 |
30 |
2.2/3 |
1900×420×700 |
0.5 |
|
ZTZY-180 |
0.3～1/0.5 |
180 |
20 |
5.5 |
2500×550×800 |
0.8 |
|
ZTZY-250 |
0.8～3/0.93 |
250 |
16 |
7.5 |
3100×650×900 |
1 |
|
ZTZY-315 |
2～5/1.6 |
315 |
16 |
11 |
4100×790×1320 |
2 |
|
ZTZY-400 |
5～13/2 |
400 |
10 |
22 |
4700×990×1420 |
4 |
|
ZTZY-500 |
8～18/3.3 |
500 |
9 |
37 |
6100×1200×1500 |
6 |
|
ZTZY-630 |
15～35/4.2 |
630 |
9 |
45 |
6800×1350×1650 |
7.5 |
|
ZTZY-800 |
25～50/7 |
800 |
7 |
75 |
7500×2300×2200 |
9 |
|
ZTZY-1000 |
30～70/8.5 |
1000 |
6 |
90 |
8100×2700×2600 |
12 |
