Description
Fruit and Vegetable Juice Pre-treatment Production Line
Feeding by belt conveyor- Crushing- Extruding- Discharging by screw conveyor
Feeding by belt conveyor- Crushing- Extruding- Dehydarte- Discharging by belt conveyor
Feeding by screw conveyor- Crushing- Extruding- Seperate- Discharging by screw conveyor
Technical Parameter
| Model | Capacity（t/h） | screw diameter（mm） | rotate speed（r/min） | Power（kw） | Dimensions: length * width * height（mm） | Weight（t） |
| ZTZY-120 | 0.1～0.3/0.26 | 120 | 30 | 2.2/3 | 1900×420×700 | 0.5 |
| ZTZY-180 | 0.3～1/0.5 | 180 | 20 | 5.5 | 2500×550×800 | 0.8 |
| ZTZY-250 | 0.8～3/0.93 | 250 | 16 | 7.5 | 3100×650×900 | 1 |
| ZTZY-315 | 2～5/1.6 | 315 | 16 | 11 | 4100×790×1320 | 2 |
| ZTZY-400 | 5～13/2 | 400 | 10 | 22 | 4700×990×1420 | 4 |
| ZTZY-500 | 8～18/3.3 | 500 | 9 | 37 | 6100×1200×1500 | 6 |
| ZTZY-630 | 15～35/4.2 | 630 | 9 | 45 | 6800×1350×1650 | 7.5 |
| ZTZY-800 | 25～50/7 | 800 | 7 | 75 | 9600×1860×2100 | 15 |
| ZTZY-1000 | 30～70/8.5 | 1000 | 6 | 90 | 11000×3100×2800 | 35 |
Application
